black line = actual tracker
blue line = ITTF tracker
| tracker type | N hits on track | px (GeV/c) | py (GeV/c) | pz (GeV/c) | p (GeV/c) | pt (GeV/c) | eta | phi (rad) with
[0,2Pi] range |
| MC | 0.5 | 2.8 | ||||||
| Actual | 0.567 | 0.1527 | 4.803 | 4.83 | 0.5875 | 2.797 | 0.2629 | |
| ITTF | 8 | 0.577 | -0.1555 | 4.891 | 4.83 | 0.5983 | 2.798 | 6.0209 |
| MC | 0.5 | 3.0 | ||||||
| Actual | 0.4418 | 0.1083 | 4.534 | 5.413 | 0.4139 | 2.994 | 0.244 | |
| ITTF | 10 | 0.456 | -0.1119 | 4.68 | 4.704 | 0.469 | 2.9949 | 6.0432 |
| MC | 0.5 | 3.2 | ||||||
| Actual | 0.401 | 0.0999 | 4.534 | 5.079 | 0.413 | 3.20 | 0.244 | |
| ITTF | 10 | 0.414 | -0.103 | 5.2 | 5.253 | 0.4274 | 3.200 | 6.039 |
black line = actual tracker
blue line = ITTF tracker
 |
 |
 |
 |
